Continuous Motion Side Sealer

E-shrink’s continuous motion side sealer offering for applications demanding high throughput speeds with maximum package flexibility. The products are packed with continuous product flow without stop and go. This machine is servo controlled and reaches speeds up to 120 packs/min. Servo system enhances machine reliability and movement accuracy so as to reduce error and cost of resources. Flexibility and ease-of-use are hallmarks of E-shrink design. 99 memories can be recorded for easy adjustment. HS-400 obtains advance configuration and capable of matching with various kinds of infeed system. Infeed modules include power conveyor, finger chain conveyor, flight bar conveyor etc.

In the same situation, HS-400/T-400 compare to Automatic L-sealer can help end user to save production cost up to 50% in terms of Electric power, Films and Man Power.

The distance between the front and rear conveyor belt can get closer for packing small products. When sealing happen, the rear conveyor will pull back for sealing bar to go downward.

To use with color printed films for ensure preset bag length per pack.

Devices to change single sheet POF films to center fold form. Save 50% of time to films changing to increase efficiency.

Feeding devices with grouping function are specially designed to feed products to form a multi packing. Several products can drive together on the same time to prohibit misalignment happen. Packaging quality is improved because of this. It can increase production speed compare to feed multi products by hand. Connecting to the existing production line can accomplish a fully automatic production.

A guide rail pushing system is employed to pushing product in muti-packs format. Depends on products height and shape, different guide rail pushing systems are available.

Finger conveyor contains quick change flight lugs with stainless steel surface. With product guide rail, it is mostly used for driving a cluster to fit a wide range of products. Program connected to subsequent shrink wrapper and missing products detection is provided. Tailor made in different specifications are available.

Friction feeder is mounted at the right angles on a finger conveyor. A set of products such as envelops, booklets, cards, paper sheet can be counted and fed on the finger conveyor which connects to subsequence shrink wrapper.

Harmonic conveyor ensures product stability under high production speed. Overhead-belt or side-belt is available.

High yield for massive production
Servo drive system ensures precise and stable performance
Capable to plug-in separate optional infeed systems for connect numerous production line
Simple setup system and operation through user friendly touch screen design.
Help customer reduce production cost dramatically from man power, electricity and films.
